1．Product Specification :
Protection class: IP65
Light source :LED
LifePO4 Battery:537.6WH
Solar panel rate Power: 85(W)
Solar panel Voltage :18 (V)
Total luminous Flux: 5000LM
LED Qty:32pcs
Duration of sunshine :8 (h)
Lifespan: 500000 (h)
Monocrystalline solar panel:18V/85W Efficiency up to 21%
2．Technique specs
| PV Module | Pmax | 85W |
Vmp | 18.2 | |
Voc | 21.7 | |
Cell efficiency | 20.6% | |
Number of cell in series | 35 | |
Dimension | 1160*418mm | |
LED chip | LED chip | LG/Cree/Nichia |
Viewing angel | Viewing angel ，70°*150°IESNA TAPE II | |
Color Temperature： | 3000K~3500K（warm white）/6000K-6500K(cool white) | |
Color rendering index | >=70 | |
Nominal luminous flux | Tj=25℃:5000lm | |
Delivered Lumens | Tj=66℃:4500lm | |
Lifespan | 50000hours | |
Lifepo4 battery | Battery capacity | 537.6WH |
lifespan | 5-8 years | |
Certification | CB, SGS, MSDS | |
Operating temperature | Charging 0-45℃ | |
Discharging -20-60℃ | ||
Mppt controller | Working voltage/ current | 12.8v 10A |
Work mode | Timing mode | |
Light control(capable of detecting day and night , automatically turning on and off during night and day ) | ||
PIR sensor mode (opitional0 | ||
Protection | Incorporate protection from reverse polarity(solar panel or battery ), over-charge , over-discharge , over load , short circuit and lightning |
Solar light features
1. Solar Panel auto cleaning system( Optional )
2. Smart Internet system,remote controlling,make the real inteligient lighting (Optional)
3. 5-8 years lifetime top level LIFE PO4 battery, withstand high temperature up to 60 degree,safe and no exploded risk.
4. Unique heat dissaption design and battery case inside ensure the lighting working performance.
5. Super brightness LED Chip : CREE / PHILIP/LG/ SAMSUM best SMD and COB led chip, best solution by own tech up to ensure 180lm/ W lumen.
6.High Strength entirety aluminium profile,gorgeous and durable.
7. Professional street light illumination distribution
8. Efficiency >21.5% solar panel
9.90 degree by 360 degree angle adjustable holder,no shadow.
