Ø 灯具参数Lighting parameters
|
LED 模组数量 LED Chips Quantity |
1 Pcs |
||
|
工作电压 Working Voltage |
DC10-16V |
DC10-28V |
|
|
系统功耗System Consumption |
10W |
||
|
LED发光效率
LED Luminous Efficiency |
70-80Lm /W |
||
|
色温Color Temperature |
2700K～7000K+（红red*橙orange） |
||
|
灯具始光光效
Lamp’s Initial Luminous Efficiency |
≥70Lm /W |
||
|
流明维持率 Lumen Maintenance |
70%(50000Hrs) |
||
|
显色指数Color Rendering Index |
Ra≥70 |
||
|
配光曲线 Light Distribution |
请参考附件测试报告 Please refer to the attachment test report
|
见下图
Daniell
|
|
|
工作温度 Operating Temperature |
|
||
|
储存环境温度 Storage Temperature |
|
||
|
防护等级IP Grade |
IP65 |
||
|
光源寿命Life-span |
50000Hrs |
||
|
材质Materials |
铝材 Aluminium |
||
|
灯具类型Appliance Class |
Ⅰ类灯具 Class Ⅰ |
||
|
灯具颜色The color of the lamp shell |
黑色/银色 Black/Silver |
||
|
电池循环寿命Cycle life |
≥300 times |
||
|
电池容量Capacity |
4400mAh/7.4V or 2200 mAh/7.4v |
||
|
充电时间Charging Time |
6～7Hrs(4400 mAh) 3-3.5Hrs(2200 mAh) |
||
|
工作时间Working Time |
≥4Hrs(4400 mAh) /≥2Hrs(2200 mAh) |
||
