Product

LED Flood light

80w led flood light

80w led flood light
80w led flood light Display pictures2
  • Model NO.F80WA
80w led flood light Description
Model NO.
F80WA
Lumens 7200lLm Beam Angle 120° or 60°
Power Consumption 80 W Certified CE & RoHS & C-TICK
Average Life in Hrs 100,000 Bulb Type Epistar/ Bridgelux
Color Rendering Index Ra>80 Equivalent To 600 Watts
Power Factor >0.9 Voltage AC85~240V
Ambient Temperature -40℃~+50℃ IP Grade IP65
Net Weight 6.5Kg Color Temperature 2700K~8000K /RED/Blue /Green
80w led flood light Shape Structure:

Shell Material：Aluminum Shell

Color： silver gray/Black/white（>50PCS）

Size:

Solar led light | LED flood light | LED High Bay Light |LED Street light





80w led flood light Illumination Distance/illuminance/Irradiated Area

Solar led light | LED flood light | LED High Bay Light |LED Street light

80w led flood light fixtures Photomatric Data:

Solar led light | LED flood light | LED High Bay Light |LED Street light

80w led flood light fixtures installation:

1. Choose the location for your new light fitting giving considerations to the points listed opposite(Mounting method reference).

2. Isolate mains.
3. mark fixing points by using the stirrup fixing holes A B C(Picture 1) and drill three fixing holes.
4. Terminate loose ends of wire to an appropriate IP rated junction box or similar, ensuring the Live, Earth and Neutral polarities are observed(Picture 2).
5. Restore power and test the floodlight.
6. Adjust floodlight head towards the area to be illuminated and lock off using two clamping bolts(Picture 3).


Solar led light | LED flood light | LED High Bay Light |LED Street light

Solar led light | LED flood light | LED High Bay Light |LED Street light



LED flood light,LED Street Lights, China led flood light and led Street lighting products manufacturer
