LED Flood light

20w led pir flood light

Model NO.F20WA-PIR

20w led pir light Description

Model NO.		F20WA-PIR
Lumens	1800lLm	Beam Angle	120° or 60°
Power	20 W	Certified	CE & RoHS & C-TICK
Average Life in Hrs	100,000	Bulb Type	Epistar/ Bridgelux
Color Rendering Index	Ra>80	Equivalent To	150 Watts
Power Factor	>0.9	Voltage	AC85~240V
Ambient Temperature	-40℃~+50℃	IP Grade	IP65
Net Weight	1.2Kg	Color Temperature	2700K~8000K /RED/Blue /Green
Time-delay	5sec~5min	Detection Distance	4~6M(<25℃)

20w led pir light Shape Structure:

Shell Material：Aluminum Shell

Color： silver gray/Black/white（>50PCS）

Size:

Solar led light | LED flood light | LED High Bay Light |LED Street light

LED PIR Flood lights 10W~50W:

Solar led light | LED flood light | LED High Bay Light |LED Street light

20w led pir light Illumination Distance/illuminance/Irradiated Area

Solar led light | LED flood light | LED High Bay Light |LED Street light

20w led pir light Photomatric Data:

Solar led light | LED flood light | LED High Bay Light |LED Street light

20w led pir light installation:

1. Choose the location for your new light fitting giving considerations to the points listed opposite(Mounting method reference).

2. Isolate mains.

3. mark fixing points by using the stirrup fixing holes A B C(Picture 1) and drill three fixing holes.

4. Terminate loose ends of wire to an appropriate IP rated junction box or similar, ensuring the Live, Earth and Neutral polarities are observed(Picture 2).

5. Restore power and test the floodlight.

6. Adjust floodlight head towards the area to be illuminated and lock off using two clamping bolts(Picture 3).
